NSA Codebreaker 2025 - Task 5: Putting It All Together

The investigative handoff from malware to infrastructure

17 October 2025 · 10 min read · Cryptanalysis

NSA analysts confirm that there is solid evidence that this binary was at least part of what had been installed on the military development network. Unfortunately, we do not yet have enough information to update NSA senior leadership on this threat. We need to move forward with this investigation!

The team is stumped - they need to identify something about who was controlling this malware. They look to you. “Do you have any ideas?”


Task

Submit the full URL to the adversary’s server


Writeup

This task provides no new files. Everything we need is already in the packet capture from Task 2 and the implant unpacked in Task 4. The implant gives us the code behind an encrypted conversation in the capture. The goal is to use it to recover the keys and read the adversary’s server URL.

The malware uses AES, but the way it generates keys and encrypts messages leaves enough information to recover both keys in under a minute on a laptop. The interesting part is how the weaknesses fit together: the small key space makes searching practical, and predictable padding gives us something to search for.

The conversation we could not read

Back in Task 2 I flagged one TCP conversation between the infected host and an outside server that started with the odd marker bytes de c0 de c0 ff ee. Following that stream shows a tidy back-and-forth of seven messages:

The seven-message C2 handshake in the Task 2 capture

Cross-referencing this with the Comms class in the Task 4 payload, the exchange is a handshake:

  1. The server sends an RSA public key in the clear.
  2. The client makes up two AES keys, encrypts them with that RSA public key, and sends them back. RSA here is just an envelope: only the server (which holds the matching private key) can open it, so the keys are hidden from anyone watching the wire.
  3. The server replies KEY_RECEIVED in the clear.
  4. From here on both sides talk using those AES keys. There are four encrypted messages left, and the last ones are where the URL lives.

Every message, once decrypted, begins with the same dec0dec0ffee marker. Hold onto that fact, it turns out to be the crowbar.

A two-minute crypto primer

If you already know AES you can skip this. If not, here is everything you need for this task:

  • A symmetric cipher like AES scrambles data with a secret number called a key. Whoever has the key can scramble (encrypt) and unscramble (decrypt). AES works on 16-byte chunks called blocks.
  • The key is normally 128 bits, a number between 0 and roughly 340 undecillion (2^128). You cannot guess it by trying every value: even at a billion billion guesses a second you would not finish before the sun burns out. That huge space of possibilities is the entire reason AES is safe.
  • ECB mode is the simplest way to use a block cipher: chop the message into 16-byte blocks and encrypt each one on its own. It is simple and, as we will see, leaky.
  • A known-plaintext attack is when you already know what some encrypted message says. If you know both the plaintext and its ciphertext, you can test a guessed key by encrypting the plaintext yourself and checking whether you get the matching ciphertext.

The malware’s security rests entirely on that 2^128 number being too big to search. All three flaws below chip away at exactly that.

Flaw 1: the keys are almost entirely zero

Looking at gen_key in the payload, it starts out doing the right thing: it reads 32 bytes of real randomness from /dev/random. Then it throws nearly all of it away. After a chain of hashing, XORs and bit shifts, the net effect is that only the low 26 bits survive. The finished 16-byte key always looks like this:

XX XX XX 0Y 00 00 00 00 00 00 00 00 00 00 00 00
|__________|  \__ the rest of the key is always zero
  26 bits that actually vary (0Y is only 0x00-0x03)

In plain terms: instead of 2^128 possible keys, there are only 2^26, which is about 67 million. That is not a cryptographic key space, that is a number a laptop chews through in seconds. Both AES keys the malware generates have this same weakness.

Flaw 2: ECB with no randomization leaks structure

AES-ECB has a well-known property: the same 16-byte input always encrypts to the same 16-byte output under a given key. There is no IV (initialization vector), the random salt that normally makes two identical blocks encrypt differently. Here there is none, so identical plaintext blocks are visible as identical ciphertext blocks.

You can see it directly in the capture. The last 16 bytes of all four encrypted messages are byte-for-byte identical:

msg4 tail: 409a5a9dafac6df2db0a970fb723a1bb
msg5 tail: 409a5a9dafac6df2db0a970fb723a1bb
msg6 tail: 409a5a9dafac6df2db0a970fb723a1bb
msg7 tail: 409a5a9dafac6df2db0a970fb723a1bb

That repeated block is padding (explained next), and because ECB leaks it, it hands us a free crib.

Flaw 3: double encryption that helps the attacker

The author clearly worried that one layer of AES was not enough, so send_message encrypts every message twice, first with key 1, then the result again with key 2. The idea is “twice the encryption, twice the safety.” It does not work that way when each key only has 26 bits, and it actually leaks a gift.

The implementation uses PKCS#7 padding to make each encryption input a whole number of 16-byte blocks. If the input is already a multiple of 16 bytes, PKCS#7 adds a full block of sixteen 0x10 bytes. The first encryption produces whole blocks, so the second layer always adds that same padding block. Crucially, this new block has never passed through key 1: it is encrypted with key 2 alone. That explains the identical tails in the capture and gives us a known-plaintext pair for the outer key.

The cribs

Putting the flaws together, I have two pieces of known plaintext:

  • For key 2 on its own: the plaintext 10 10 ... 10 (sixteen 0x10 bytes) encrypts to that repeated tail block 409a5a9d...a1bb.
  • For both keys together: from the implant’s handshake code, the first encrypted client message is the string REQCONN. With the dec0dec0ffee marker in front and PKCS#7 padding behind, its first 16-byte plaintext block is exactly dec0dec0ffee524551434f4e4e030303, and we can see its ciphertext in the capture.

The attack

Now the 2^26 key space does all the work. Two quick phases, each a plain brute force:

  1. Recover key 2. Try all ~67 million candidate keys. For each, decrypt the repeated tail block. The correct key is the one that turns it back into sixteen 0x10 bytes.
  2. Recover key 1. Peel the key-2 layer off the REQCONN ciphertext block to get the value sitting between the two encryptions. Then try all ~67 million candidates again: the correct key 1 is the one that encrypts the known dec0dec0ffee...REQCONN block into that middle value.

Each phase is about 67 million AES operations, a few seconds in compiled code. (A meet-in-the-middle attack on a single doubly-encrypted block works too, but peeling the layers using the free key-2 crib is simpler.)

Here is the solver in Rust. It links AES from the system’s OpenSSL, recovers both keys, then decrypts all four messages:

// NSA Codebreaker 2025 - Task 5 solver
//
// The implant (unpacked in Task 4) wraps each C2 message in double AES-128-ECB with no IV.
// Its key generator is broken: each 16-byte key is `v` as 4 little-endian bytes followed by
// 12 zero bytes, with v in [0, 2^26) (bytes 0-2 random, byte 3 in 0..=3). That is only 26 bits
// of entropy per key, so the two keys fall to a known-plaintext brute force.
//
// Cribs taken from the Task 2 capture + protocol constants:
//   * every message ends with E_k2(0x10^16): the second encryption layer's PKCS#7 block,
//     encrypted with key 2 only -> recover key 2 directly.
//   * the first application message decrypts to  dec0dec0ffee + "REQCONN" + PKCS#7(0x03) ->
//     once key 2 is known, recover key 1.
//
// AES comes from libcrypto (linked below); no third-party crates.

#[link(name = "crypto")]
extern "C" {
    fn AES_set_encrypt_key(user_key: *const u8, bits: i32, key: *mut AesKey) -> i32;
    fn AES_set_decrypt_key(user_key: *const u8, bits: i32, key: *mut AesKey) -> i32;
    fn AES_encrypt(inp: *const u8, out: *mut u8, key: *const AesKey);
    fn AES_decrypt(inp: *const u8, out: *mut u8, key: *const AesKey);
}

// OpenSSL AES_KEY: unsigned int rd_key[60]; int rounds;  -> 244 bytes. Over-allocate for safety.
#[repr(C)]
struct AesKey {
    rd_key: [u32; 60],
    rounds: i32,
}
impl AesKey {
    fn zero() -> Self { AesKey { rd_key: [0; 60], rounds: 0 } }
}

const MAX: u32 = 1 << 26;

fn key_from_v(v: u32) -> [u8; 16] {
    let mut k = [0u8; 16];
    k[..4].copy_from_slice(&v.to_le_bytes());
    k
}

fn enc_block(key: &[u8; 16], inp: &[u8; 16]) -> [u8; 16] {
    let mut ak = AesKey::zero();
    let mut out = [0u8; 16];
    unsafe {
        AES_set_encrypt_key(key.as_ptr(), 128, &mut ak);
        AES_encrypt(inp.as_ptr(), out.as_mut_ptr(), &ak);
    }
    out
}

fn dec_block(key: &[u8; 16], inp: &[u8; 16]) -> [u8; 16] {
    let mut ak = AesKey::zero();
    let mut out = [0u8; 16];
    unsafe {
        AES_set_decrypt_key(key.as_ptr(), 128, &mut ak);
        AES_decrypt(inp.as_ptr(), out.as_mut_ptr(), &ak);
    }
    out
}

fn unhex(s: &str) -> Vec<u8> {
    (0..s.len()).step_by(2).map(|i| u8::from_str_radix(&s[i..i + 2], 16).unwrap()).collect()
}

// AES-128-ECB decrypt a whole buffer with one key, then strip PKCS#7 padding.
fn decrypt_layer(key: &[u8; 16], data: &[u8]) -> Vec<u8> {
    let mut out = Vec::with_capacity(data.len());
    for ch in data.chunks_exact(16) {
        let mut b = [0u8; 16];
        b.copy_from_slice(ch);
        out.extend_from_slice(&dec_block(key, &b));
    }
    let pad = *out.last().unwrap() as usize;
    if pad >= 1 && pad <= 16 && pad <= out.len() {
        out.truncate(out.len() - pad);
    }
    out
}

fn main() {
    // Cribs and messages from this capture (stream 19).
    let pad_ct = unhex("409a5a9dafac6df2db0a970fb723a1bb");            // E_k2(0x10^16)
    let reqconn_ct = unhex("42703d2f1090e0e0556125071e3b6469");        // first block of msg4
    let reqconn_pt = unhex("dec0dec0ffee524551434f4e4e030303");        // dec0..+REQCONN+PKCS7
    let messages = [
        ("msg4 C->S", "42703d2f1090e0e0556125071e3b6469409a5a9dafac6df2db0a970fb723a1bb"),
        ("msg5 S->C", "eb11c256aafe5abe289cd8f04f7241afb3f5b4ba9ecd9a03e5a7f108aecb18b9409a5a9dafac6df2db0a970fb723a1bb"),
        ("msg6 C->S", "1332db1a443b7ef7f27b1b448002cd10563c504e8963aa3bc46091f5b36678c29fed247b555ba5a3f45e185aa3df8b27409a5a9dafac6df2db0a970fb723a1bb"),
        ("msg7 S->C", "3610982eaa90dbf184bab42e23f7bb17bac652c79d19f17706c66e01f6affc0c9538c9b4c64dd2f68587edd0e6eea7fdc2dabd1252a0136764895a764c5e98e9409a5a9dafac6df2db0a970fb723a1bb"),
    ];

    let pad_pt = [0x10u8; 16];
    let mut pad_ct_a = [0u8; 16]; pad_ct_a.copy_from_slice(&pad_ct);
    let mut rc_a = [0u8; 16];     rc_a.copy_from_slice(&reqconn_ct);
    let mut pt_a = [0u8; 16];     pt_a.copy_from_slice(&reqconn_pt);

    // Phase 1: key 2 from the single-key padding crib.
    let mut v2 = None;
    for v in 0..MAX {
        if dec_block(&key_from_v(v), &pad_ct_a) == pad_pt { v2 = Some(v); break; }
    }
    let v2 = v2.expect("key 2 not found");
    let k2 = key_from_v(v2);

    // Phase 2: key 1.  D_k2(reqconn_ct) == E_k1(reqconn_pt)
    let inter = dec_block(&k2, &rc_a);
    let mut v1 = None;
    for v in 0..MAX {
        if enc_block(&key_from_v(v), &pt_a) == inter { v1 = Some(v); break; }
    }
    let v1 = v1.expect("key 1 not found");
    let k1 = key_from_v(v1);

    println!("key1 = {}", k1.iter().map(|b| format!("{:02x}", b)).collect::<String>());
    println!("key2 = {}", k2.iter().map(|b| format!("{:02x}", b)).collect::<String>());
    println!();

    // Decrypt each message: outer layer k2, inner layer k1.
    for (name, hexmsg) in messages {
        let ct = unhex(hexmsg);
        let inner = decrypt_layer(&k2, &ct);
        let plain = decrypt_layer(&k1, &inner);
        let body = &plain[6..]; // drop dec0dec0ffee header
        println!("{name}: {}", String::from_utf8_lossy(body));
    }
}

Result

Both keys fall out in about 20 seconds, and the messages decrypt cleanly:

Solver output: recovered keys and decrypted messages

The first two decrypted messages are REQCONN and REQCONN_OK, exactly the handshake plaintext we predicted, which confirms the keys are correct. Then the client asks the server DATA REQUEST mattermost_url, and the server answers with the prize:

key1 = 2b086a03000000000000000000000000
key2 = cd914a00000000000000000000000000

msg4 C->S: REQCONN
msg5 S->C: REQCONN_OK
msg6 C->S: DATA REQUEST mattermost_url
msg7 S->C: https://198.51.100.166/mattermost/5wN1amoCUByjy

Submission

The full URL to the adversary’s server:

https://198.51.100.166/mattermost/5wN1amoCUByjy
